Stone Coated Roof Tile Production Line made from natural sand, with advanced high-pressure technology to make traditional roof tile rendering 3D stereo effect.

Unique pleated design groove, so that the roof tiles to each other more tightly grip more firmly, then water and better performance.

It has a metal plate performance, easy cutting and processing, single tile large area and light weight. Steel tile unique convex design so that each piece of tile steel are closely linked to each other, by means of its unique levels nails embedded system, firmly fixed in the roof.

Technical parameters:

1.Auto bottom gule spraying section

l Appearance size:4000*1000*2000 mm

l Driving section:3KW Excitation motor or frequency speed regulation (as requirements )

l Automatic pressure spray tank:1set capability:200kg Range:0.6~1Mpa

l Automatic glue machine motor: Servo motor, Power:750w, plc

l Automatic spray gun:4 set(spare parts)

l Dust collecting fan: 1set power:200w

l Damp proof lamp:1pc power:100w

l Conveying device:Chain reciprocating

l Air compressor:1set power:7.5kw

l Dust control of axial flow fan:1set power: 200w

l Agitator: 1set power:1.5kw

2.Auto stone coated section

l Appearance size:3500×1000×1500mm
l Framework: Steel welding
l Conveying device:Chain reciprocating
l Automatic sand hopper: 1set capability:200kg
l Bucket lift:1 set

l Manual sandblast gun:4sets

3.The first time drying section

l Appearance size:25000×1000×1200 mm
l Framework: Steel welding
l Frame type thermal insulation wall: 1.2mm cold steel with Rock wool
l Automatic temperature controller:4set Range:0°~160°
l Infrared heating tube: 30pcs Power:30kw
l Conveying device:Chain reciprocating
l Air cooling device:1 set Power:200w

4,Auto face glue spraying section
l Appearance size:3000×1000×2000 mm
l Framework: Steel welding
l Damp proof lamp:1pc Power:100w
l Automatic pressure spray tank:1set capability:200kg Range:0.6~1Mpa
l Conveying device:Chain reciprocating
l Automatic spray gun:4 set(spare parts)
l Manual patch glue gun:4 set
l Dust control of axial flow fan:1set power: 200w
l Automatic glue machine motor: Servo motor, Power:750w

5.The second time drying section
l Appearance size:30000×1000×1200 mm
l Framework: Steel welding
l Frame type thermal insulation wall: 1.2mm cold steel with Rock wool
l Automatic temperature controller:4set Range:0°~160°
l Infrared heating tube: 30pcs Power:30kw
l Conveying device:Chain reciprocating
l Air cooling device:1 set Power:200w

Pictures of machine:

Training and Installation :
1. We offer installation service local in paid, reasonable charge.
2. QT test is welcome and professional.
3. manual and using guide is optional if no visiting and no installation.

Certification and after service:
1. Match the technology standard, ISO producing certification
2. CE certification
3. 12 months warranty since the delivery. Board.

Our advantages:
1. Short delivery period.
2. Effective communication
3. Interface customized.
